大口径法兰
-
重量单位为：KG
| HG20623 A系列大直径管法兰和法兰盖近似重量 | |||||||||||||||||
| 公称尺寸 | PN2.0 CLass150 | PN5.0 CLass300 | PN11.0 CLass600 | PN15.0 CLass900 | |||||||||||||
| DN | NPS | 法兰 | 法兰盖 | 临时单价/KG | 法兰 | 法兰盖 | 临时单价/KG | 法兰 | 法兰盖 | 临时单价/KG | 法兰 | 法兰盖 | 临时单价/KG | ||||
| 20# | 304 | 20# | 304 | 20# | 304 | 20# | 304 | ||||||||||
| 650 | 26 | 136.2 | 318.8 | 274.7 | 489.5 | 426.8 | 798.6 | 692.4 | 1165 | ||||||||
| 700 | 28 | 156.7 | 378.2 | 338.3 | 597.1 | 481.3 | 935.7 | 821.8 | 1442.9 | ||||||||
| 750 | 30 | 181.6 | 445.9 | 395 | 700.6 | 549.4 | 1100 | 962.5 | 1706.2 | ||||||||
| 800 | 32 | 229.3 | 561.6 | 30.5 | 456.3 | 815 | 624.3 | 1296.7 | 1155.5 | 2061.7 | |||||||
| 850 | 34 | 245.2 | 628.4 | 519.9 | 938.9 | 699.2 | 1469.6 | 1348.4 | 2463 | ||||||||
| 900 | 36 | 290.6 | 761 | 30 | 578.9 | 1106 | 774.1 | 1726.2 | 1541.4 | 2818.9 | |||||||
| 950 | 38 | 326.9 | 825.9 | 908.5 | 667.4 | 1545.5 | 1536.8 | 2838.9 | |||||||||
| 1000 | 40 | 351.9 | 926.2 | 381.4 | 1080.6 | 740.1 | 1742.5 | 1643.5 | 3150.8 | ||||||||
| 1050 | 42 | 404.1 | 1081 | 431.3 | 1220.4 | 921.7 | 2081.6 | ||||||||||
| 1100 | 44 | 449.5 | 1233.6 | 479 | 1397.9 | 980.7 | 2317.7 | ||||||||||
| 1150 | 46 | 481.3 | 1344.3 | 560.7 | 1588.6 | 1094.2 | 2614.2 | ||||||||||
| 1200 | 48 | 538 | 1520 | 626.6 | 1768.8 | 1296.2 | 3058.6 | ||||||||||
| 1250 | 50 | 576.6 | 1687.1 | 594.7 | 2016.7 | 1511.9 | 3493.6 | ||||||||||
| 1300 | 52 | 640.2 | 1886.9 | 753.7 | 2227.4 | 1616.3 | 3825.5 | ||||||||||
| 1350 | 54 | 719.6 | 2106.2 | 930.7 | 2580.6 | 1779.7 | 4237.2 | ||||||||||
| 1400 | 56 | 799.1 | 2330 | 978.4 | 2768.5 | 1943.2 | 4780.2 | ||||||||||
| 1450 | 58 | 869.5 | 2576.7 | 1030.6 | 3027.8 | 2106.6 | 5182 | ||||||||||
| 1500 | 60 | 928.5 | 2794 | 1121.4 | 3302.4 | 2270 | 5951.1 | ||||||||||
